MIL-DTL-6070C
TABLE II. Veneer Thickness and Tolerances (8 to 12 Percent Moisture Content) .
Veneer Thickness
Tolerances
Inch
Inch
0.011
+ .001
0.020
+ .002
0.030
+ .002
0.034
+ .003
0.040
+ .003
0.047
+ .003
0.060
+ .003
0.068
+ .004
0.080
+ .004
0.095
+ .004
TABLE III. Permissible Panel Construction.
Number
Plywood
of Plies
Thickness
Thickness of Plies in Inches (8-12 Percent Moisture Content)
and
Tolerances
Group I or II Faces with
All Group I or
All Group III
in Inches
Group II Inner Plies
All Group II
F&B
XB
C
F&B
XB
C
F&B
XB
C
1/
3
.035 +.004
--
--
--
.011
--
.011
--
--
--
3
.070 +.007
.020
.030
.020
.030
.020
.034
3
100 +.008
..030
.040
.030
.040
.030
.047
3
.125 +.010
.034
.060
.034
.060
.034
.068
3
.155 +.011
.040
.080
.040
.080
.040
.080
3
.185 +.012
.047
.095
.047
.095
.047
.095
5
.160 +.012
.030
.034
.030
.030
.034
.030
.030
.034
.030
5
.190 +.015
.034
.047
.034
.034
.047
.030
.034
.047
.034
5
.225 +.015
.040
.060
.030
.040
.060
.030
.040
.060
.034
5
.250 +.015
.047
.060
.047
.047
.060
.047
.047
.060
.047
5
.315 +.015
.060
.080
.047
.060
.080
.040
.060
.080
.047
5
.375 +.018
.060
.095
.080
.060
.095
.080
.060
.095
.080
7
.410 +.020
All Plies
.060
7
.460 +.022
All Plies
.068
7
.540 +.023
All Plies
.080
9
.590 +.025
All Plies
.068
2/
9
.695 +.028
All Plies
.080
2/
11
.085 +.035
All Plies
.080
2/
11
1.010 +.035
All Plies
.095
2/
NOTES: 1/ All plies of 0.035 inch plywood must be of Group I species.
2/ Faces, backs, and outer cross-bands of plywood having nine or more plies must be of the same
species.
CODE: F&B = Face and Back; XB = Cross Bands; C = Core
